Breakout Board Kit for Wouxun KG-1000G / KG-UV980P
Breakout Board Kit for Wouxun KG-1000G / KG-UV980P
SKU: BB-KG1000G
The BTWR Essentials BB-KG1000G is an interface designed to seamlessly integrate your Wouxun KG-1000G+ radios with advanced repeater controllers like the ID-O-Matic (IDOM). The ID-O-Matic can connect to it and be used to provide an auto ID. This board bridges the gap between modern GMRS radios and repeater controllers, eliminating the need for bulky relay boards or custom solutions.
In Stock
$19.99
Description / Breakout Board Kit for Wouxun KG-1000G / KG-UV980P
The BTWR Essentials BB-KG1000G is an interface designed to seamlessly integrate your Wouxun KG-1000G+ radios with advanced repeater controllers like the ID-O-Matic (IDOM). The ID-O-Matic can connect to it and be used to provide an auto ID.
This board bridges the gap between modern GMRS radios and repeater controllers, eliminating the need for bulky relay boards or custom solutions. The BB-KG1000G simplifies the connection process, enhances signal handling, and ensures compatibility across various repeater configurations.
This board bridges the gap between modern GMRS radios and repeater controllers, eliminating the need for bulky relay boards or custom solutions. The BB-KG1000G simplifies the connection process, enhances signal handling, and ensures compatibility across various repeater configurations.
- Ideal for GMRS repeater setups needing auto-ID capabilities
- Supports advanced configurations for dual-channel repeater systems or single-channel ID overlays
- Enhanced COR Signal Management:
- Integrated Power Handling
- Audio Passthrough Flexibility
- Equipped with a DIP switch for selective audio routing
- Pass-Through Mode: Direct audio transfer between RX and TX
- IDOM Integration Mode - Routes received audio through the ID-O-Matic for CW or voice overlay functionality
- Compact and Durable Design
- Plug-and-Play Compatibility
- Simplifies installation with a 6-pin connector and clear pin mapping for GND, BUSY, PTT, TX_AUDIO, RX_AUDIO, and IN+
- Uses standard RJ45 cables (straight-through wiring) for effortless integration without modifications
- Optimized for Real-World Applications
- Designed to handle the unique requirements of GMRS repeaters, including CW ID during active transmissions
- Enhanced audio clarity through an optional high-pass filter toggle to suit various radio setups
- Works with Wouxun KG-1000G, KG-1000G Plus and KG-UV980 Mobile Two Way Radios.
Included with the BB-KG1000G Breakout Board Kit
- 1x KG-1000G+ Breakout Board
- DIP switch configuration reference chart
- 2x RJ-45 Interface Patch Cables
More Information
| Connector | RJ45 |
|---|---|
| Warranty | 6 Months |
